RIGOL Digital Oscilloscope 12-bit 25 Mpts Ultra Acquire

The RIGOL DS1074Z is a 70 MHz digital oscilloscope designed for professional and educational use. It features 4 analog input channels, a high sampling rate of 1.25 GSa/s, and a 12-bit vertical resolution that provides enhanced detail for signal analysis. The instrument offers a deep memory depth of up to 25 Mpts per channel. Its Ultra Acquire mode achieves a waveform capture rate of up to 1,000,000 wfms/s, combined with 256-level intensity grading and a comprehensive waveform search function to quickly identify and navigate to infrequent events and glitches. Standard features include peak detection for capturing narrow glitches down to 1.6 ns, a 1 Mpts FFT math function for frequency analysis, and support for 41 automatic measurements. The oscilloscope includes built-in serial protocol triggering and decoding for CAN, RS232/UART, I2C, SPI, and 4-bit parallel buses using its analog channels. Connectivity options include LAN with LXI-C and Web Control support, USB host and device ports, and an HDMI output for external display. It is equipped with a 7-inch capacitive touch screen with a resolution of 1024 x 600 pixels and features a Flex Knob for intuitive parameter adjustment. This oscilloscope is well-suited for applications such as power supply ripple and noise measurement, embedded system development, sensor interface validation, and digital protocol debugging.
